SQ CR33 Galvanized Steel Coil Strip 1500mm Hot Dipped

Place of Origin China,Jiangsu,Wuxi
Brand Name CY STEEL Metal
Certification ISO9001
Model Number SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550)
Minimum Order Quantity 2 ton
Price $513~$540/ton
Packaging Details Standard seaworthy export packing: waterproof paper+steel trippacked+wooden case seaworthy package
Delivery Time 10-30days
Payment Terms D/A, T/T, Western Union
Supply Ability 20000 Ton/Tons per Year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Galvanized Steel Length As You Requested
Width 600-1500mm(usual Size:914mm,1000mm,1200mm,1219mm,1250mm,1220mm) Thickness 0.1-6 Mm
Sample Available Delivery Time 7-15 Days
High Light

SQ CR33 Galvanized Steel Coil

,

Galvanized Steel Coil 1500mm

,

Hot Dipped Galvanized Steel Coil Strip

Leave a Message
Product Description
Product Description

Galvanized Sheetl Coil | 0.14-5mm in Thick | China Factory

Description of conventional galvanized sheet

Galvanized sheet is a thin steel sheet with Q235 as the base material immersed in a molten zinc tank to adhere a layer of zinc

on the surface. It is mainly produced by continuous galvanizing process. That is, the coiled steel plate is continuously immersed

in the galvanized bath with molten zinc to make the galvanized steel plate, and then cut by the flattening machine and the

shearing machine.


Common specifications:
Thickness: 0.14-5mm.
Width: 600-1500mm.
Zinc Coated: 30-275g/sqm.
Spangle: Standard spangle, large spangle, small spangle, non-spangle (Regular, Big, Mini, Non-spangle).

Technical Standard
EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653
Steel Grade
Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490,
SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ
CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement
Type
Coil/Sheet/Plate/Strip
Thickness
0.12-6.00mm,or customer's requirement
Width
600mm-1500mm, according to customer's requirement
Type of Coating
Hot Dipped Galvanized Steel(HDGI)
Zinc Coating
30-275g/m2
Surface Treatment
Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)
Surface Structure
Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS)
Quality
Approved by SGS,ISO
ID
508mm/610mm
Coil Weight
3-20 metric ton per coil
Package
Water proof paper is inner packing,galvanized steel or coated steel sheet is outer packing , side guard plate,then wrapped by
seven steel belt.or according to customer's requirement
Export market
Europe, Africa, Central Asia, Southeast Asia, Middle East, South America, North America, etc





Remark:

Hot-dip galvanizing is the reaction of molten metal with an iron substrate to produce an alloy layer, thereby
combining the substrate and the plating layer. Hot-dip galvanizing is to pickle iron and steel parts first. In order
to remove iron oxide on the surface of iron and steel parts, after pickling, it is cleaned in an ammonium chloride
or zinc chloride aqueous solution or a mixed solution of ammonium chloride and zinc chloride.And then sent to
the hot-dip plating bath. Hot-dip galvanizing has the advantages of uniform coating, strong adhesion and long service life.

Factory Produced
SQ CR33 Galvanized Steel Coil Strip 1500mm Hot Dipped 0
SQ CR33 Galvanized Steel Coil Strip 1500mm Hot Dipped 1
SQ CR33 Galvanized Steel Coil Strip 1500mm Hot Dipped 2
Product Display
SQ CR33 Galvanized Steel Coil Strip 1500mm Hot Dipped 3

SQ CR33 Galvanized Steel Coil Strip 1500mm Hot Dipped 4







SQ CR33 Galvanized Steel Coil Strip 1500mm Hot Dipped 5
SQ CR33 Galvanized Steel Coil Strip 1500mm Hot Dipped 6



SQ CR33 Galvanized Steel Coil Strip 1500mm Hot Dipped 7
SQ CR33 Galvanized Steel Coil Strip 1500mm Hot Dipped 8



Product packaging
SQ CR33 Galvanized Steel Coil Strip 1500mm Hot Dipped 9
SQ CR33 Galvanized Steel Coil Strip 1500mm Hot Dipped 10
SQ CR33 Galvanized Steel Coil Strip 1500mm Hot Dipped 11
SQ CR33 Galvanized Steel Coil Strip 1500mm Hot Dipped 12
SQ CR33 Galvanized Steel Coil Strip 1500mm Hot Dipped 13



Application field
SQ CR33 Galvanized Steel Coil Strip 1500mm Hot Dipped 14
Certifications
