SGHC Galvanized Steel Coil SGH340 SGH400 6.00mm

Place of Origin China
Brand Name Chengyue jinshu
Certification ISO9001
Model Number SGCC, SGHC, SGCH, SGH340, SGH400, SGH440
Minimum Order Quantity ≥1 ton
Price $518~$548/ton
Packaging Details Standard Sea-worthy Packing
Delivery Time 15-25days
Payment Terms D/A, T/T, Western Union, MoneyGram
Supply Ability 20000 Ton/Tons per Year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Galvanized Steel Coil Shape Rolled
Spangle Mini, Normal, Reuglar Spangle, Minimized, Zero Application Flange Plate, Commercial Use, Forming,roofing
Technique Hot Rolled, Cold Rolled Surface Treatment Coated, Galvanized
High Light

SGHC Galvanized Steel Coil

,

SGH340 Galvanized Steel Coil

,

6.00mm Galvanized Steel Coil

Leave a Message
Product Description
Product Description

Galvanized Sheetl Coil | 0.14-5mm in Thick | China Factory

Description of conventional galvanized coil

Galvanized sheet is a thin steel sheet with Q235 as the base material immersed in a molten zinc tank to adhere a layer of zinc

on the surface. It is mainly produced by continuous galvanizing process. That is, the coiled steel plate is continuously immersed

in the galvanized bath with molten zinc to make the galvanized steel plate, and then cut by the flattening machine and the

shearing machine.


Common specifications:
Thickness: 0.14-5mm.
Width: 600-1500mm.
Zinc Coated: 30-275g/sqm.
Spangle: Standard spangle, large spangle, small spangle, non-spangle (Regular, Big, Mini, Non-spangle).





Technical Standard
EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653
Steel Grade
Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490,
SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ
CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement
Type
Coil/Sheet/Plate/Strip
Thickness
0.12-6.00mm,or customer's requirement
Width
600mm-1500mm, according to customer's requirement
Type of Coating
Hot Dipped Galvanized Steel(HDGI)
Zinc Coating
30-275g/m2
Surface Treatment
Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)
Surface Structure
Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS)
Quality
Approved by SGS,ISO
ID
508mm/610mm
Coil Weight
3-20 metric ton per coil
Package
Water proof paper is inner packing,galvanized steel or coated steel sheet is outer packing , side guard plate,then wrapped by
seven steel belt.or according to customer's requirement
Export market
Europe, Africa, Central Asia, Southeast Asia, Middle East, South America, North America, etc



Remark:

Hot Dipped Galvanized Steel Sheet in Coil (GI) is produced by passing the Full Hard sheet which has undergone the acid washing process and rolling process through the zinc pot, thereby applying zinc film to the surface. It has excellent corrosion resistance, paintability, and workability due to Zinc’s characteristics. Usually, hot-dipped galvanized steel sheet and galvanized steel coil process and specifications are basically the same.

Factory Produced
SGHC Galvanized Steel Coil SGH340 SGH400 6.00mm 0
SGHC Galvanized Steel Coil SGH340 SGH400 6.00mm 1
SGHC Galvanized Steel Coil SGH340 SGH400 6.00mm 2
Product Display
SGHC Galvanized Steel Coil SGH340 SGH400 6.00mm 3

SGHC Galvanized Steel Coil SGH340 SGH400 6.00mm 4







SGHC Galvanized Steel Coil SGH340 SGH400 6.00mm 5
SGHC Galvanized Steel Coil SGH340 SGH400 6.00mm 6



SGHC Galvanized Steel Coil SGH340 SGH400 6.00mm 7
SGHC Galvanized Steel Coil SGH340 SGH400 6.00mm 8



Product packaging
SGHC Galvanized Steel Coil SGH340 SGH400 6.00mm 9
SGHC Galvanized Steel Coil SGH340 SGH400 6.00mm 10
SGHC Galvanized Steel Coil SGH340 SGH400 6.00mm 11
SGHC Galvanized Steel Coil SGH340 SGH400 6.00mm 12
SGHC Galvanized Steel Coil SGH340 SGH400 6.00mm 13



Application field
SGHC Galvanized Steel Coil SGH340 SGH400 6.00mm 14
Certifications

FAQ

1. Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer with 1.5 million tons of steel annually in China. We have passed the factory inspection by various international organizations and have our own sales team. Welcome to seeing and inspecting our factory
2. Q: Do you have quality control system?
A: Yes,we have iso,bv,sgs certifications and our own quality contorl laboratory.
3. Q: How long is your delivery time?
A: Within 7-15 days after receiving the deposit or L/C at sight. Longer lead time will be required for special designed products.
4. Q: Do you provide samples ? is it free or extra ?
A:Yes, we could offer the sample for free charge but the delivery charges will be covered by our customers.
5. Q: Do you provide after-sale service?
A: We provide after-sales service and offer 100% guarantee on our products.
