Coated 90% Aluminum Sheets Metal Plate 7075 Aircraft Grade
| Place of Origin | China |
|---|---|
| Brand Name | chengyue |
| Certification | ISO9001 RoHS |
| Model Number | 7075 |
| Minimum Order Quantity | 1 ton |
| Packaging Details | Waterproof paper, and steel strip packed According to requirements |
| Delivery Time | 6 days |
| Payment Terms | L/C D/A D/P T/T Western Union MoneyGram |
| Supply Ability | 3000 tons per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Aircraft Grade Aluminum Sheets | Grade | 7075 |
|---|---|---|---|
| Surface Treatment | Coated Embossed Hairline Polished Plain | Width | Customer Requirement 10mm~2500mm 1200mm 500mm-2800mm 600-2000mm |
| Alloy Or Not | Is Alloy Non-alloy | Temper | O-H112,T3-T8,Other,O,T351-T851 |
| Thickness | 0.2mm-200mm 0.15-300 Mm 0.10mm~500mm 0.45MM 0.5mm/1mm/1.5mm / 2mm / 3mm /4mm/5mm/etc. | ||
| High Light | 90% Aluminum Sheets Metal,7075 aircraft aluminum sheet,7075 90% Aluminum Sheets Metal |
||
Product Description
Aluminum Sheets 90% Aluminum Component Al Plate 7075 Aircraft Grade Aluminum With High Strength
Description of Aluminum Thick Plate 7075-t651 Products
- Typical thickness:80um,100mm,110mm,130mm,97mm,105mm,75mm,91mm,can bu custom
- Typical specification:1530*2270,can be custom
- Hardness(HB):150HB
- Density:2810
- Alloy:7075
- Temper :T651,T7351
- Standard :EN485-2008
Features of Aluminum Thick Plate 7075-t651
- High strength
- High hard alloy aluminum with heat treatable
- Great mechanical properties
- Great usability
- Easy to process and Solderability
- Thick plate,large specification
Applications of 7075 Aluminum
Type 7075 aluminum is one the strongest aluminum alloys. Its high yield strength (>500 MPa) and its low density make the material a fit for applications such as aircraft parts or parts subject to heavy wear. While it is less corrosion resistant than other alloys (such as 5052 aluminum alloy, which is exceptionally resistant to corrosion), its strength more than justifies the downsides. Some major applications of 7075 aluminum alloy include:
- Aircraft fittings
- Gears and shafts
- Missile parts
- Regulating valve parts
- Worm gears
- Aerospace/defense
Product Paramenters
7075-t651 Chemical Composition
| Range | Si | Fe | Cu | Mn | Mg | Cr | Zn | Each | total | Aluminum |
| Min. | - | - | 1.2 | - | 2.1 | 0.18 | 5.1 | - | - | Remainder |
| Max. | 0.4 | 0.5 | 2.0 | 0.3 | 2.9 | 0.28 | 6.1 | 0.05 | 0.15 |
7075 Aluminum Plate Specifications
|
Tensile Strength Rm(Mpa) |
Yield Strength Rp0.2(Mpa) |
Elongation (%) |
| 524~572 | 445~503 | Min.12.0 |
Aluminum Plate 7075-t651 Specification
| Alloy Series | Typcial Alloy | Typcial Tempe |
Thickness (MM) |
Width (MM) |
Length (MM) |
| 7series | 7075 | T351,T651,T451,T751 | 4-16 | 900-2600 | 1000-2400 |
| 16-260 | 900-3800 | 1000-38000 |
Product Display
