1060 H24 Aluminum Sheet Metal Roll 3003 H14 H22 For Construction

Place of Origin China
Brand Name chengyue
Certification ISO9001 RoHS
Model Number 1000 series
Minimum Order Quantity 1 ton
Packaging Details Waterproof paper and steel strip packed According to requirements
Delivery Time 6-8 Days
Payment Terms L/C D/A D/P T/T Western Union MoneyGram
Supply Ability 3500 tons per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Alloy 1000 Series Temper H22 H24 H26 H28 H112
Application Construction Building Decoration Roofing Ceiling Type Coil Roll Coil Plate Roll Coil Plate Roll Sheet Aluminum Coil Aluminum Strip
Standard ASTM AISI JIS DIN GB ASTM-B209 Package Wooden Pallet Or As Customer's Requirement Wooden Pallet Standard Seaworthy Package
Surface Light Is Flat And Level Thickness 0.1mm-6.5mm
High Light

1060 H24 Aluminum Sheet Metal Roll

,

aluminium sheet roll 3003 H14

,

aluminium sheet roll 3003 For Construction

Leave a Message
Product Description

Factory Aluminum Coil 1060 H24 Metal Sheet Roll 3003 H14 H22 Roll Low Price Aluminum Coil



The most common type is A91100 which is commercially pure aluminum. It is soft and very ductile, having excellent workability. Well suited for applications involving severe forming as it work hardens more slowly during forming. It is the most weldable of all aluminum alloys.



Aluminum comes in three basic types: 1100, 3003, and 6061. The grade of the aluminum will determine the end-use application and price point. For example, 1100 is a lower-cost material than 6061 but cannot be used for high-temperature applications like cooking utensils or pot lids.



Product Paramenters



1)1000 Series Alloy (Generally called commercial pure aluminum,Al>99.0%)
Purity 1050 1050A 1060 1070 1100
Temper O/H111 H112 H12/H22/H32 H14/H24/H34 H16/
H26/H36 H18/H28/H38 H114/H194, etc.
Specification Thickness≤30mm; Width≤2600mm; Length≤16000mm OR Coil (C)
Application Lid Stock, Industrial Device, Storage, All Kinds of Containers, etc.
Feature Lid Shigh conductivity, good corrosion resistant performance, high latent heat
of melting, high-reflectance, well welding property, low strength, and not
suitable for heat treatments.

1100 aluminum coil properties

Alloy Temper Specified Tensile strength Yield strength Elongation
Thickness(in.) (KSI) (KSI) (%)
1100-O (annealed) 0.006-0.019 11.0-15.5 Min3.5 Min15
0.020-0.031 Min20
0.032-0.050 Min25
0.051-0.249 Min30
0.250-3.000 Min28
1100-H12/1100-H22 0.017-0.019 14.0-19.0 Min11.0 Min3
0.020-0.031 Min4
0.032-0.050 Min6
0.051-0.113 Min8
0.114-0.499 Min9
0.500-2.000 Min12
1100-H14/1100-H24 0.009-0.012 16.0-21.0 Min14.0 Min1
0.013-0.019 Min2
0.020-0.031 Min3
0.032-0.050 Min4
0.051-0.113 Min5
0.114-0.499 Min6
0.500-1.000 Min10
1100-H16/1100-H26 0.006-0.019 19.0-24.0 Min17.0 Min1
0.020-0.031 Min2
0.032-0.050 Min3
0.051-0.162 Min4
1100-H18/1100-H28 0.006-0.019 Min22.0 - Min1
0.020-0.031 Min2
0.032-0.050 Min3
0.051-0.128 Min4
1100-H112 0.025-0.499 Min13.0 Min7.0 Min9
0.500-2.000 Min12.0 Min5.0 Min14
2.001-3.000 Min11.5 Min4.0 Min20



Factory Produced
1060 H24 Aluminum Sheet Metal Roll 3003 H14 H22 For Construction 0
1060 H24 Aluminum Sheet Metal Roll 3003 H14 H22 For Construction 1
1060 H24 Aluminum Sheet Metal Roll 3003 H14 H22 For Construction 2
1060 H24 Aluminum Sheet Metal Roll 3003 H14 H22 For Construction 3
1060 H24 Aluminum Sheet Metal Roll 3003 H14 H22 For Construction 4
Product Display
1060 H24 Aluminum Sheet Metal Roll 3003 H14 H22 For Construction 5

1060 H24 Aluminum Sheet Metal Roll 3003 H14 H22 For Construction 6
1060 H24 Aluminum Sheet Metal Roll 3003 H14 H22 For Construction 7





Product packaging
1060 H24 Aluminum Sheet Metal Roll 3003 H14 H22 For Construction 8
1060 H24 Aluminum Sheet Metal Roll 3003 H14 H22 For Construction 9
Applications
1060 H24 Aluminum Sheet Metal Roll 3003 H14 H22 For Construction 10
Certifications

Aluminum Tube Supplier 6061 5083 3003 Anodized Round Pipe 7075 T6 Aluminum Pipe 12



FAQ



1. Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer with 1.5 million tons of aluminum annually in China. We have passed the factory inspection by various international organizations and have our own sales team. Welcome to seeing and inspecting our factory

2. Q: Do you have quality control system?
A: Yes,we have iso,bv,sgs certifications and our own quality contorl laboratory.

3. Q: How long is your delivery time?

A: Within 7-15 days after receiving the deposit or L/C at sight. Longer lead time will be required for special designed products.

4. Q: Do you provide samples ? is it free or extra ?
A:Yes, we could offer the sample for free charge but the delivery charges will be covered by our customers.

5. Q: Do you provide after-sale service?
A: We provide after-sales service and offer 100% guarantee on our products.
